RD-Monoguard SG
Technical sheetFast drying Primer/Finish high performance anti-corrosion coating with universal adherence.
RD-Monoguard is part of a new generation of water-based anti-corrosion coatings offering long-lasting protection equivalent to traditional zinc-rich epoxy-polyurethane systems with the great advantage of not necessarily having to blast the surface before application!!
Based on a unique formula combining the essential performance required for coatings on metals: very high adhesion and protection against corrosion, high resistance against water, erosion, UV and long durability.
RD-Monoguard has been tested by independent laboratories and is certified to be applied in marine and industrial environments classified C5 and to protect steel for more than 15 years according to ISO 12944.
The use of RD-Monoguard as a replacement for traditional solvent-based systems allows working with more safety, comfort and ease, but also faster. Being single-component and water-based, it is also much more environmentally friendly by emitting far fewer VOCs and drastically reducing the amount of waste.
Calculate here the amount of paint needed for your project
Technical sheet
Description of the product
USE:
Fast drying Primer/Finish high performance anti-corrosion coating with universal adherence.
FEATURES:
Single component water-based coating based on a special blend of innovative resins for the protection of metal surfaces, objects and engineered structures against corrosion and weathering. RD-Monoguard is a DTM (Direct-To-Metal) type of coating that can be applied directly to various type of ferrous and non-ferrous metals. Its special formulation and ingredients offer incredible durability when it comes to protecting steel against corrosion, even without priorly blasting the surface.
RD-Monoguard is water-based, easy to handle, safe and has no fire risks. It is a fast-drying coating system that greatly reduces downtime during installation and increases on-site labour productivity.
Virtually odour free, it does not affect neighbouring occupants and can therefore be used in occupied buildings.
RD-Monoguard is UV resistant and its film forms a neat and tidy enamel type of finish.
Tested to be used in the most severe environments, RD-Monoguard protects valuable assets worldwide 24/7 including bridges, tanks, etc.
RD-Monoguard is part of the SCS – Single Coating System - product group.
SUBSTRATES:
Steel, new and old galvanised steel, stainless steel, aluminium, copper, …
Systems
Steel located in aggressive marine & industrial environments – C5 High | Wet film thickness in microns / mils | Dry film thickness in microns / mils | Consumption per m² / ft² per gallon | Comments | |
Primer | RD-Monoguard | 233 / 9,3 | 100 / 4 | 0,23 l / 175 | High lifespan > 15 years |
Finish | RD-Monoguard | 233 / 9,3 | 100 / 4 | 0,23 l / 175 | |
TOTAL | 200 / 8 | 0,46 l / 87 | |||
Other option: | |||||
Primer | RD-Monoguard | 230 / 9 | 100 / 4 | 0,23 l / 175 | High lifespan > 15 years |
Finish | RD-Hydrograff HP Gloss | 105 / 4,2 | 50 / 2 | 0,10 l / 390 | |
TOTAL | 150 / 6 | ||||
Other option in case of old and rusty surface: | |||||
Primer | RD-Elastometal | 386 / 15,4 | 220 / 8,8 | 0,48 kg / 106 | High lifespan > 15 years |
Finish | RD-Monoguard | 186 / 7,4 | 80 / 3,2 | 0,19 l / 219 | |
TOTAL | 300 / 12 |
Steel located in aggressive marine & industrial environments – C4 | Wet film thickness in microns / mils | Dry film thickness in microns / mils | Consumption per m² / ft² per gallon | Comments | |
Primer | RD-Monoguard | 174 / 7 | 75 / 3 | 0,17 l / 234 | High lifespan > 15 years |
Finish | RD-Monoguard | 174 / 7 | 75 / 3 | 0,17 l / 234 | |
TOTAL | 150 / 6 | 0,34 l / 117 | |||
Other option: | |||||
Primer | RD-Monoguard | 186 / 7,4 | 80 / 3,2 | 0,19 l / 219 | High lifespan > 15 years |
Finish | RD-Hydrograff HP Gloss | 83 / 3,3 | 40 / 1,6 | 0,08 l / 488 | |
TOTAL | 120 / 4,8 | ||||
Other option in case of old and rusty surface: |
|
|
|
| |
Primer | RD-Elastometal | 315 / 13 | 175 / 7 | 0,4 kg / 130 | High lifespan > 15 years |
Finish | RD-Monoguard | 186 / 7,4 | 80 / 3,2 | 0,19 l / 219 | |
TOTAL |
| 255 / 10,2 |
Steel located in moderate environments – C3 | Wet film thickness in microns / mils | Dry film thickness in microns / mils | Consumption per m² / ft² per gallon | Comments | |
Primer | RD-Monoguard | 128 / 5,1 | 55 / 2,2 | 0,13 l / 319 | High lifespan > 15 years |
Finish | RD-Monoguard | 128 / 5,1 | 55 / 2,2 | 0,13 l / 319 | |
TOTAL | 110 / 4,4 | 0,26 l / 160 | |||
Other option in case of old and rusty surface: |
|
|
|
| |
Primer | RD-Elastometal | 214 / 8,5 | 120 / 4,8 | 0,27 kg / 190 | High lifespan > 15 years |
Finish | RD-Monoguard | 186 / 7,4 | 80 / 3,2 | 0,19 l / 219 | |
TOTAL |
| 200 / 8 |
|
Risks of chemical spills or graffitis:
The system can be top coated by one or two coats of RD-Hydrograff HP Clear High Gloss if not already used in the system.
Indicated consumption is theoretical and does not consider potential losses during application. It can also be influenced by the porosity of the substrate.
Application instructions
APPLICATION CONDITIONS:
Ambient temperature: minimum 5°C (41°F) – optimal between 12 and 25°C (54 and 77°F).
Relative humidity: maximum 80%
Surface temperature must be minimum 3°C (5°F) above dew point.
APPLICATION MEANS:
Brush, roller or airless (nozzle size: 010–012)
Application by airless is recommended and makes it easier to reach the recommended thicknesses. Use a device that allows a minimum pressure of 70-150 bar / 1000 - 2000 psi at the outlet.
PREPARATION OF THE SUBSTRATE:
The substrate must be clean: dry, degreased and dust free. Non adhering elements such as older coatings or rust must be removed. Different type of surface preparation are possible:
1/ Remove rust manually or by power tool to ST2 – ISO 8501-1/SSPC SP2 or SP3.
2/ Blasting to SA 2½ - ISO 8501-1/NACE3/SSPC SP6.
3/ High pressure washing following SSPC SP12 WJ4.
Aluminum: clean with sulfuric acid diluted to 10%.
On new galvanized steel: preferably clean with RD-Eco PowerClean detergent diluted with water or use a conventional detergent.
Stainless steel: preferably clean with RD-Eco PowerClean detergent diluted with water or use a conventional detergent.
Copper: clean with hydrochloric acid diluted to 10% and rinse with water.
DILUTION:
Product is ready-for-use. Dilute with maximum 3% water when applying by airless or in warm weather conditions (> 25°C / > 77°F).
DRYING TIME (20°C - 68°F):
Touch dry: +/- 1 hour depending on thickness
Recoatable: +/- 2 hours depending on film thickness
Possible to apply wet on wet in special conditions.
CLEANING OF TOOLS:
Water
SPECIFICITIES:
Mix well before use.
Technical data
FINISH (Gardner 60°):
Semi-Gloss +/- 70 % +/- 5
COLOURS:
White. Also available in clear, check RD-Monoguard Clear.
RAL, NCS and bespoke colours. Available on RD Coatings dispensing system.
DENSITY:
1.15 +/- 0.05 g/cm³
SOLIDS CONTENT:
In weight: 51 % +/-2
In volume: 43 % +/-2
VISCOSITY:
30 - 50 P (Brookfield 20RPM)
VOC CONTENT:
< 45 g/l
FLASH POINT:
Not flammable
STORAGE:
Minimum 24 months protected from frost and excessive temperatures in its original closed packaging.
Norms and tests
SALT SPRAY | ISO 9227 / ISO 4628 |
WATER CONDENSATION | ISO 6270 / ISO 4628 |
ADHESION | ISO 2409 |
HARDNESS PERSOZ | ISO 1522 |
HARDNESS PENCIL | ISO 15184 |
![]() | ISO 16000-6 / VOC Classification in France |
Safety data
Information related to hygiene and to safety can be found in the Safety Data Sheet available on request.
These specifications are given for information. Since the manufacturer is not able to check the application of the products, he cannot accept any responsibility for it. This technical data sheet replaces all previous editions.
VERS. S051/230222

Fast drying Primer/Finish high performance anti-corrosion coating with universal adherence.
